Short Circuit Analysis

short circuit analysisA short circuit analysis determines the short circuit currents available at various points in the electrical distribution system. Knowledge of these values is critical in determining the rating of each piece of equipment in a facility’s electrical system.

Benefits of a Short Circuit Analysis

  1. Ensures Safety of Personnel and Equipment
    1. Identifies locations where fault currents may exceed equipment ratings, which could lead to equipment failure or fire.
    2. Helps prevent arc flash incidents by ensuring protective devices operate correctly during faults
    3. Reduces the risk of catastrophic equipment damage and injuries.
  2. Verifies Equipment Ratings
    1. Confirms whether equipment like circuit breakers, fuses, busbars, switchgear, and transformers are properly rated to handle the worst-case short-circuit currents.
    2. Prevents installing under-rated equipment, which could fail during a fault.
  3. Supports Proper Protective Device Coordination
    1. Essential input for protective device coordination studies, ensuring that the correct breaker trips at the right time and place, minimizing system downtime and isolating faults efficiently.
  4. Informs Arc Flash Studies
    1. Provides the available fault current values needed for calculating incident energy levels in arc flash risk assessments (as per NFPA 70E and IEEE 1584).
  5. Improves System Reliability and Uptime
    1. Identifies potential weak points in the system before a fault occurs.
    2. Allows for corrective actions like replacing underrated components or adjusting protection settings, reducing chances of unplanned outages.
  6. Supports System Design and Upgrades
    1. Aids engineers in designing safe and compliant power systems.
    2. Essential when adding new loads, generators, transformers, or upgrading breakers.
    3. Ensures that system changes don’t introduce dangerous fault current levels.
  7. Helps with Code Compliance
  8. Reduces Maintenance and Operational Costs
    1. Prevents costly equipment replacements and downtime due to avoidable failures.
    2. Reduces the chance of nuisance tripping or overloading, which can interrupt critical operations.
  9.  Establishes a Baseline for Ongoing Analysis

IBPS Engineers are dedicated to the client’s needs to assure the integrity of their electrical system.
